產品介紹
| ? Technology | |
| Standards | IEEE 802.3 for 10BaseT IEEE 802.3u for 100BaseT(X), 100BaseFX |
| ? Interface | |
| RJ45 Ports | 10/100BaseT(X) |
| Fiber Ports | 100BaseFX (SC/ST connectors) |
| LED Indicators | PWR, Fiber Link, 10/100M (TP port) |
| ? Optical Fiber | |
| ? Physical Characteristics | |
| Dimensions | 86.8 x 124.3 x 21 mm (3.42 x 4.89 x 0.83 in) |
| Weight | Product only: CSM-400-1213/1214/1218: 115 g (0.25 lb) CSM-400-1224/1225: 125 g (0.28 lb) Packaged: CSM-400-1213/1214/1218: 170 g (0.37 lb) CSM-400-1224/1225: 180 g (0.40 lb) |
| ? Environmental Limits | |
| Operating Temperature | Standard Models: -20 to 55°C (-4 to 131°F) Wide Temp. Models: -40 to 75°C (-40 to 167°F) |
| Storage Temperature | -40 to 85°C (-40 to 185°F) |
| Ambient Relative Humidity | 5 to 95% (non-condensing) |
| ? Power Requirements | |
| Input Voltage | 12 VDC |
| Input Current | 220 mA @ 12 VDC max. |
| ? Standards and Certifications | |
| Safety | UL 60950-1 |
| EMC | EN 55032/24 |
| EMI | CISPR 32, FCC Part 15B Class A |
| EMS | EN 61000-4-2 (ESD): Contact: 4 kV; Air: 8 kV EN 61000-4-3 (RS): 80 MHz to 1 GHz: 3 V/m EN 61000-4-4 (EFT): Power: 1 kV; Signal: 0.5 kV EN 61000-4-5 (Surge): Power: 1 kV; Signal: 0.5 kV EN 61000-4-6 (CS): 150 kHz to 80 MHz: 3 V/m EN 61000-4-8 (PFMF) EN |
| Freefall | IEC 60068-2-32 |
| ? MTBF (mean time between failures) | |
| Time | 1,454,560 hrs |
| Standard | Telcordia (Bellcore), GB |
| ? Warranty | |
| Warranty Period | 5 years |
Available Models
| Model No. | Description | |
|---|---|---|
| CSM-400-1213 | 10/100BaseT(X) to 100BaseFX slide-in management module converter, multi-mode ST connector, -20 to 55°C | |
| CSM-400-1213-T | 10/100BaseT(X) to 100BaseFX slide-in management module converter, multi-mode ST connector, -40 to 75°C | |
| CSM-400-1214 | 10/100BaseT(X) to 100BaseFX slide-in management module converter, multi-mode SC connector, -20 to 55°C | |
| CSM-400-1214-T: | 10/100BaseT(X) to 100BaseFX slide-in management module converter, multi-mode SC connector, -20 to 55°C | |
| CSM-400-1218 | 10/100BaseT(X) to 100BaseFX slide-in management module converter, single-mode SC connector, -40 to 75°C | |
| CSM-400-1218-T | 10/100BaseT(X) to 100BaseFX slide-in management module converter, single-mode SC connector, -20 to 55°C | |
| CSM-400-1224 | 10/100BaseT(X) to 100BaseFX slide-in management module converter, WDM-A single-mode SC connector, -20 to 55°C | |
| CSM-400-1224-T | 10/100BaseT(X) to 100BaseFX slide-in management module converter, WDM-A single-mode SC connector, -40 to 75°C | |
| CSM-400-1225 | 10/100BaseT(X) to 100BaseFX slide-in management module converter, WDM-B single-mode SC connector, -20 to 55°C | |
| CSM-400-1225-T | 10/100BaseT(X) to 100BaseFX slide-in management module converter, WDM-B single-mode SC connector, -40 to 75°C |
